Hofmann

Geodyna 7200 S

Motorized                         Yes

Wheel clamping               QuickNut

Diameter of shaft             40 mm

Measuring speed             < 200 rpm

Balancing accuracy         0.035 oz

Angular resolution           ± 0,35°

Length of shaft                225 mm

Rim diameter range        8″ – 32″

Offset range                    1″ – 20″

Rim width range              1″ – 20″

Max wheel diameter       42 inch

Max. wheel weight          154 lbs

Input power (VAC)          230 VAC 1Ph 50/60 Hz

Dimensions LxWxH        40″ x 30″ x 72″

Hofmann Geodyna 7200 S

The geodyna® 7200s High Performance Wheel Balancing System is ideal for all shops – small footprint complimented by the video display provides high-end features in a compact design. In under ten seconds, the color display shows the location of any imbalance and identifies the optimal tape on or clip-on weight location. The fast spin cycle provides accurate measurement with minimum cycles for fast results

​

Part Number:

EEWB746AS

​

Ideal for all shops – small footprint complimented by the video display provides high-end features in a compact design

In under ten seconds, the color display shows the location of any imbalance and identifies the optimal tape on or clip-on weight location

​The fast spin cycle provides accurate measurement with minimum cycles for fast results

smartSonar simplifies parameter entry

Patented Virtual Plain Imaging (VPI) for precise measuring

Hidden weight mode

Automatic braking of the wheel after measurement

Pedal operated main shaft lock

Tire and wheel optimization program

Compact dimensions – for installation close to a wall

​

Geoliner 770

Wheel Size (AC200)   19″ – 39″

Tire Size (AC400)       19″ – 39″

Power supply115 VAC 1Ph 50/60 Hz

Track width                  48″ – 96″

Wheel base                 79″ – 180″

Hofmann Geoliner 770

Ideal for high-volume shops that specialize in alignments and wheel service, the Hofmann® geoliner® 770 Mobile Imaging Wheel Aligner delivers sophistication in a compact footprint, designed to fit where you need it and move pretty much anywhere else.The short boot-up gets your team to every job quickly, with faster measurements for more efficient, more accurate alignments every time.

​

Part Numbers

With AC 400 Clamps & Vin Reader – EEWA752BV3

With AC 200 Clamps & Vin Reader – EEWA752HV3

​

Groundbreaking User Interface –

The geoliner® 770 Mobile Imaging Wheel Aligner features a next-generation interface that provides instant access to critical tasks in an intelligent flow, ensuring vehicle-specific assistance is never more than just one click away.

Optimized Vehicle Selection Process
– Quick access to history right on the home screen
– Clear and comprehensive make/year/model selection
– Quick model search
– Manual and scanner VIN select, with live lookup feature

Quick-Select Language Support for Procedures and Printouts

– provide rapid changes between commonly used languages

All-New Graphic Displays

– with all screens optimized for maximum visibility and clarity

Video Speed Cameras Constantly Monitor Alignments, Providing Information at Every Step

– The geoliner® 770 Mobile Imaging Wheel Aligner’s advanced XD cameras and sophisticated monitoring algorithms find errors as they’re made, detecting problems with suspension stress and damage, rack, clamps, environment, and more – notifying users only when necessary, to save time and ensure accuracy on every alignment.

Compensate: Error is completely compensated with no notification to the user

Warn: Error is completely compensated with user warned that a correction action is required

Alert: Critical error leading to a bad alignment is detected; user notified that corrective action is required

Automatic Height Tracking Save Time on Every Job

– The geoliner® 770 Mobile Imaging Wheel Aligner automatic height tracking provides optimum placement of its advanced XD targets and cameras for more speed and more accuracy on every alignment. And since the lightweight, three-camera system folds to a compact size with a low center of gravity, the geoliner® 770 takes up less floor space in the shop and can be moved around easily whenever required.

With the AC400 wheel clamps, it virtually eliminates any worry of damaging rims by attaching with a single fast-action adjustment knob and only makes contact with the tire.​

Additional Features

Next generation UI optimized for the high-volume user

Diagnostic alignment with “Compensate Warn Alert” intervention gets it right the first time

Unique camera beam design to fit through a standard doorway and protects cameras

Highly accurate and reliable XD camera technology

Geodyna 7100

Motorized                         Yes

Wheel clamping               QuickNut

Diameter of shaft             40 mm

Measuring speed             < 100 rpm

Balancing accuracy         0.035 oz

Angular resolution           ± 0,35°

Length of shaft                225 mm

Rim diameter range        8″ – 32″

Offset range                    1″ – 20″

Rim width range              1″ – 20″

Max wheel diameter       37.8 inch

Max. wheel weight          154 lbs

Input power (VAC)          230 VAC 1Ph 50/60 Hz

Dimensions LxWxH        43.3″ x 39.6″ x 67.4″

Hofmann Geodyna 7100

The geodyna® 7100 offers space-saving usability, with belt-driven one-spin balance, the VPI measuring system, user-friendly 2D SAPE data entry and an intuitive control panel.

​

Part Number:

EEWB761AE1

​

Small footprint

Semi-automatic input of offset and rim diameter via 2D SAPE

Manual input of rim width

Conspicuous and intuitive LED display

Imbalance minimization and optimization programs

VPI measurement technique for uncompromised accuracy

QuickBal for reduced measurement time:
Short start-stop cycle time: 6.5 seconds (15″ rim)

Measuring speed < 100 rpm

Wheel guard

Clamping of wheel on integrated flange with quick nut

Geoliner 680 XD

Tire Size (AC400)       19″ – 39″

Power supply 115 VAC 1Ph 50/60 Hz

Track width                  48″ – 96″

Wheel base                 79″ – 180″

Hofmann Geoliner 680 XD

​

Providing many of the same benefits and improved software capabilities as the geoliner® 790, the geoliner® 680 XD Imaging Wheel Aligner combines unmatched accuracy and user-friendly features with a conventional imaging aligner design. And its extensive vehicle specifications database instills even more confidence and assures the job is done right the first time.

Accurate, real-time measurements are provided by our patented imaging technology, including high-resolution cameras and the industry’s most advanced XD targets.

​

Part Number:  EEWA714R

​

Pinpoint Alignment Problems Faster and Easier Than Ever Before

Our new, redesigned geoliner® 680 XD Imaging Wheel Aligner features improved camera and target technology and the smallest, lightest XD target system we’ve ever offered. It also provides highly accurate and repeatable measurements, to help you get the job done quicker and eliminate comebacks.

The high-resolution cameras produce accurate, live alignment readings and diagnostic data. It also utilizes passive front and rear XD targets that are highly durable. The cross-diagonal measurements identify frame damage while the rolling radius detects mismatched tire sizes, and it provides all the benefits of our AC400 Touchless Alignment Wheel Clamp.

But best of all, the geoliner® 680 XD Imaging Wheel Aligner is so lightweight and simple to operate, you don’t have to be a highly-skilled alignment tech to master it

​

AC400 Touchless Alignment Wheel Clamping System

​

VODI™ Vehicle Orientation Directional Indicator guides users through the measurement process

​

Measures camber, caster, toe, rolling radius, cross-diagonal, wheelbase and track width

​

​EZ-TOE lets you turn the front wheels and access difficult adjustment points when setting toe

Geodyna 980 L

Motorized                         Yes

Wheel clamping               QuickNut

Diameter of shaft             40 mm

Measuring speed             < 100 rpm

Balancing accuracy         0.035 oz

Angular resolution           ± 0,35°

Rim diameter range        8″ – 30″

Offset range                    1″ – 20″

Rim width range              2″ – 20″

Max wheel diameter       30 inch

Input power (VAC)          115 VAC 1Ph 50/60 Hz

Dimensions LxWxH        54″ x 55″ x 76″

Hofmann Geodyna 980 L

The geodyna® 980L heavy-duty wheel balancing system is designed to handle the balancing needs of trucks, buses, RV’s, and Light Truck/Automobile tires. The geodyna® 980L is equipped to handle from the smallest of wheels, 12″ (30.5 cm) to heavy-duty 25″ (63.5) and “super-singles”.

​

Part Number:

EEWB710BW

​

2-Plane/Dynamic wheel balancing of truck tires off the vehicle can help increase the life of the tread

The pneumatic wheel lift aids in proper wheel mountings and reduces related strains caused by lifting heavy tires

The geodyna® 980L includes truck centering cones for hub piloted wheels, professional 4-star/5-star centering arms for stud piloted applications and passenger/light truck cones for automotive use

Operator can recalibrate the balancer in two easy steps to ensure accuracy

Semi-automatic data entry precisely enters the wheel diameter and distance utilizing the geodata arm to help reduce operator errors

Flexible balancing system designed to handle from the smallest of wheels, 12″ to heavy duty 24.5″ and “super-singles”

Geoliner 678

Wheel Size (AC200)   12″ – 24″

Tire Size (AC400)       19″ – 39″

Power supply 115 VAC 1Ph 50/60 Hz

Track width                  48″ – 96″

Wheel base                 79″ – 180″

Hofmann Geoliner 678

​

Introducing the latest addition to the Hofmann® Imaging Alignment family – the geoliner® 678 Imaging Wheel Aligner.

Designed with the technician in mind, this wheel aligner offers advanced technology with the most intuitive software to give any alignment technician the tools needed for an easy and fast alignment.

​

Part Number:

With AC400 Clamps, VIN Reader & Ethos Edge – EEWA715TBEE3

With AC400 Clamps & VIN Reader – EEWA715TBV3

With AC200 Clamps, VIN Reader & Ethos Edge – EEWA715THEE3

With AC200 Clamps & VIN Reader – EEWA715THV3

​

Fast & Easy to Use

New, intuitive software is designed together with technicians to provide the core alignment functions, only one click away

Complete alignment process with minimal steps resulting in more alignments per day

Compensate, Warn, Alert diagnostic system feature is for detecting and, where possible, compensating errors without interrupting the alignment process​

​

Advanced Features

Automatic Tracking – Cameras follow the vehicle as it is raised and lowered reducing time spent at the console

​

Video Speed Camera – Allows faster compensation reducing wait time

​

Live Readings – No need to remeasure

​

Intelligent Software Tools

EZ-Toe – Allows adjustment of the critical Front Individual Toe without locking the steering column resulting in a level steering wheel

​

Rolling Radius – Checks for mismatched tire sizes, alerting possible mechanical failure (AWD)

​

Cross Diagonal – Checks for vehicle structural damage alerting possible additional repair

​

Adjustment Assistance – Shows where the adjustments are on the vehicle

​

AC400 Touchless Wheel Clamps

Touchless Design – Provides secure clamping with no wheel contact

​

Fast Setup – Get your readings faster. No adapters required!

​

Cloud Services & Online Report Management

Provides quick access to vehicle specifications and repair information, ADAS guide, technical service bulletins, recall information, TPMS information, sensor reset information, firmware updates and much more

​

Fast and easy software and vehicle specification updates

​

Access, print, email or text aligner reports

​

Body Shop Vehicle Check

Combined measurements help discover hidden damage before starting the alignment process

​

Measurements include: cross diagonal, vehicle track width and wheel base, front & rear set back, and axle offset

​

Specialized reports provide clear communication to body shop partners

​

Standard Accessories

Wheel Clamps

Brake Pedal Depressor

Color Inkjet Printer

Steering Wheel Holder

Two Wheel Chocks

18k 2 Post

Capacity                                      18000 lbs

Lifting times                                 60 s

Drive-through width                     104.25 inch

Power supply                               230 VAC 1Ph 50/60 Hz

Distance between columns         119.875 inch

Minimum ceiling height               176 inch

Overall Width                              154.75 inch

Hofmann 18k 2 Post

Hofmann® announces the release of its tested tough 18,000 lb heavy duty capacity twin post models. The twin post models have many unique features such as the adjustable stacking screw pad system, included standard adapters and extra long lifting carriages to optimize load distribution and providing smooth operation. Standard height and Extended height models available.

​

Part Number:

EELR741A

​

Heavy-duty lifting capacity of 18,000 lbs

Single point, air actuated lock release allows the technician to disengage both of the columns simultaneously

Oversized, steel pulleys reduce the stress on the equalization system and provide increased durability

60″ lifting carriage lessens stress on the column by dispersing the load

Standard combination stack screw pads and storage brackets accommodate the technician with a wide range of vehicle pick-up points

The padded overhead shut off system prevents vehicle damage from being raised too high

ANSI/ALI ALCTV:2011 – Independently Tested and Validated, ALI Certified to the current automotive lift standard

Monty 3550

Clamping range                                12″ – 28″

Outside clamping range                   12″ – 26″

Inside clamping range                      12″ – 28″

Capability                                          70 kg

Power supply                                    115 VAC 1Ph 50/60 Hz

Dimensions LxWxH                          75.6″ x 67.7″ x 89″

Weight                                               975 lbs

​

Hofmann Monty 3550

Hofmann’s monty® 3550 series of high-performance tire changers feature the industry’s most advanced capabilities to service a wide variety of wheel and tire assemblies. The monty 3550 series is specifically designed to change low-profile, high performance and run-flat tires maximizing a shop’s versatility.

​

Part Number:

EEWH747A

​​

Accommodates Large Wheel & Tire Assemblies

Allowing for a tire diameter of 47″ and an outer-wheel diameter of 26″ on the monty 3550 (30″ on monty 3550em,) the monty 3550/3550em can handle wheel and tire assemblies found on cars and light trucks

Dual Wheel Clamping Cylinders

Dual pneumatic clamping cylinders control all four clamping jaws, eliminating damage to wheel due to slippage

Four-Jaw Clamping Chuck

Self-centering and clamps wheel with either 28″ inner or 26″ outer diameter

Powerful Two-Position Bead Breaker

6,000 lbs of power at the bead shovel and a range of up to 17″ wide. The two-stage pneumatic cylinder provides precise power and can be toggled with the foot pedal as needed

Pneumatically-Controlled Mount/Demount Head

Push-button controlled mount/demount head pneumatically lowers and locks into position, automatically indexing away from the wheel to prevent contact and damage to the wheel and tire assembly

Protect the Most Delicate Wheels

All metal parts have plastic protection providing non-metal to metal contact when changing delicate wheels

​

Two-Speed Capability (EEWH747A)

7 RPM for delicate and difficult activities, 14 RPM for speed

Monty 3300

Overall Wheel Clamping Diameter   10″-24″ (25-61 cm)

Inner Wheel Clamping Diameter      12″-24″ (30.5 – 61 cm)

Outer Wheel Clamping Diameter     10″-24″ (25-61 cm)

Bead Breaker Range                        2″-17″ (5-43 cm)

Bead Loosening Power                    6,000 lbs (2,722 kg)

Max Outer Tire Diameter                  40″ (101.6 cm)

Shipping Weight (monty3300em)     855 lbs (387.8 kg)

Shipping Weight (monty3300)          625 (283.5 cm)

Power Requirements                        120V 1Ph 60Hz

​

Hofmann Monty 3300

The Hofmann® monty® 3300 and 3300em high-performance tire changers are designed for high-volume tire shops, multi-bay repair shops and car dealerships. Technicians can effortlessly & safely change standard tires or the most difficult performance tires (low-profile and run flat tires) on cars, SUVs and light trucks. The monty 3300 series feature a powerful, multi-position bead breaker that delivers 6,000 lbs of power at the bead shovel, making easy jobs of both the stiffest and softest sidewalls.

​

Part Number:

M3300110EM

​​

Accommodates Large Wheel & Tire Accessories

Allowing for a tire diameter of 40″ and an outer-wheel diameter of 24″ on the monty 3300/3300em can handle wheel and tire assemblies found on cards and light trucks

Dual Wheel Clamping Cylinders

Dual pneumatic clamping cylinders control all four clamping jaws, eliminating damage to wheel due to slippage

Multi-Position Bead Breaker

6,000 lbs of power at the bead shovel and a range of up to 17″ wide. The two-stage pneumatic cylinder provides precise power and can be toggled with the foot pedal as needed

Powerful Tire Inflation System

Powerful air blast operated by the foot pedal. Each moveable jaw is precisely set to the exact position under the wheel to seal the tire bead

Built To Last

Heavy, solid half inch thick steel clamping table. Rugged steel reinforced chassis. Rust proof air cylinders and valve. On-board compressed air lubricator and regulator

Upgradeable

EasyMont Pro features a three-piece design with a top roller, pressing foot and lifting disc. Each piece provides a specialized function that assists a single operator in mounting/demounting low-profile and high-performance tires

Monty 1675 SS

​

Outer-Clamping Diameter                10″-24″ (250 – 609.6 mm)

Inner-Clamping Diameter                 12″-24″ (304.8 – 609.6 mm)

Maximum Wheel Width                    15″ (380 mm)

Maximum Tire Diameter                   53″ (1,346 mm)

Compressed Air Supply                   110-170 PSI (7.6-11.7 BAR)

Adjustable Four Claw Clamp            Included

Integrated Bead-Seating Jets           Included

Pressure Timer                                 Included

Twin Cylinder Turntable Clamping    Included

Rotation Speed                                CW 7-18 | CCW 7 RPM

Bead Breaker Power                        2,700 lbs (12 kN)

Bead Breaker Range                        1.7″ – 16.3″ (43-414 mm)

Recommended Floor Space             53.3″ x 46.1″ x 80.75″

Shipping Weight                               750 lbs (340 Kg)

Power Requirements                        230V 1Ph 50/60Hz 16A

​

Hofmann Monty 1675 SmartSpeed

The Hofmann® 1675 tire changing system is ideal for handling passenger cars, light trucks and high-performance wheel/tire assemblies. Ergonomic design and safety enhancing features provide the technician a safe workspace when changing a variety of tires. Locking mount/demount head offset provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies.

​

Part Number:

EEWH779CU1

​​

Robust, Professional Design

Precision cast and machined shoes with robust cast jaws make for precise, slop free clamping

Heavy-duty pneumatic valves are simple to operate and offer intuitive functionality

Powerful electric motor generates 1200Nm of torque to the table top to mount stiff, difficult tires

​​

smartSpeed™ Model

Automatically minimizes damage to tires

Innovative, patented technology that optimizes the torque applied to the wheel and automatically sets the maximum rotation speed of the wheel

Variable from 7 to 18 RPM; offering the highest possible speed for maximum productivity

Ergonomic, Hand Operated Bead Breaker Control

Newly designed bead breaker is easy to use and prevents the technician from having to straddle the assembly during bead breaking

Integrated Pressure Limiter

Stops air flow once pressure has reached 55 PSI (3.5 Bar) preventing accidental tire over-inflation

Mount/Demount Head

Locking of the mount/demount head offset, which provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies

Tire Lifting Tool

Integrated bead pusher assists in the mount/demount process of the upper bead. Tire lifting tool aids the technician with the demounting process

Swing-Arm Configuration

Quick and easy setup. Stays within a compact footprint, even with larger tire sizes. Provides an ergonomic tire changing position
